+ BOLT/BAR STRAIGHTENING MACHINE

> Specification

Specification / Model DL-S102
Product dia. (mm) ø10~38
Product length (mm) 100~850
Feeding (mm) Manual feeding
Speed (pcs/min) 6~10
Machine power (kw) 2.25
Hydraulic motor (kw) 2.25
Spindle motor (kw) 7.5
Machine dimension (mm) 1550x1470x1100
Machine weight (kgs) 1720

DL-S500

DL-S501

Specification / Model DL-S500
Product dia. (mm) ø3~16
Product length (mm) 60~300
Feeding (mm) Manual feeding
Speed (pcs/min) 12~20
Machine power (kw) 6
Hydraulic motor (kw) 2.25
Spindle motor (kw) 3.75
Machine dimension (mm) 1260x1290x1070
Machine weight (kgs) 970
Specification / Model DL-S501
Product dia. (mm) ø3~16
Product length (mm) 60~300
Feeding (mm) Auto feedign
Speed (pcs/min) 6~8
Machine power (kw) 6
Hydraulic motor (kw) 2.25
Spindle motor (kw) 3.75
Machine dimension (mm) 1360x1800x1070
Machine weight (kgs) 1170

DL-S600

DL-S601

Specification / Model DL-S600
Product dia. (mm) ø3~25
Product length (mm) 60~600
Feeding (mm) Manual feeding
Speed (pcs/min) 12~20
Machine power (kw) 7.875
Hydraulic motor (kw) 2.25
Spindle motor (kw) 5.625
Machine dimension (mm) 1500x7027x1050
Machine weight (kgs) 1670
Specification / Model DL-S601
Product dia. (mm) ø3~25
Product length (mm) 60~600
Feeding (mm) Auto feedign
Speed (pcs/min) 5~8
Machine power (kw) 7.875
Hydraulic motor (kw) 2.25
Spindle motor (kw) 5.625
Machine dimension (mm) 1600x1700x1050
Machine weight (kgs) 1870
